MD 82 AX MK II is a mixer for microphones which integrates a large series of attractive features that allow to optimize the installation and to outfit with multiple audio signal control and management possibilities. This mixer incorporates 8 balanced inputs. It provides individual input level control and master level.
The encoder in the frontal side allows to navigate through a configuration menu with the different parameters on each channel. Among the functions to be performed, we can set three tone control, low-pass and high-pass filters (with frequency adjustment) and 4 anti-feedback levels. All this information is showed in the LCD display.
All inputs have switch to enable the connection of +48V phantom power supply microphones. The two features that represent an interesting development are the Auto-mixer functionality and the RS485 interface for external commands.
- 8 Channels digital mixer, Automix function
- Anti Feedback
- 1 19 inch rack unit
- Controllable from free APP for iOS and Android
Personalised advice
Do you need help choosing your product? We will be happy to help you with your project.
| Input Channels | 8 canales de micrófono (Euroblock 3 pines)/ 8 microphone channels (3-pin Euroblock) |
| Output | 1 estéreo (Euroblock 3 pines)/ 1 stereo (Euroblock 3 pin) |
| Equalization | HPF, LPF, 3 tone controls |
| Phantom Power | +48 V |
| Maximum input level | 105 mV (1kHz THD -1%) |
| Input Sensitivity | 5 mV (1kHz salida 1V)/ 5 mV (1kHz output 1V) |
| Maximum output level | < 4 V |
| Other functions | Automix with configurable target and gain, remote control iOs/Android app, RS 485 command control. |
| Dimensions | 483 x 150 x 44mm |
| Weight | 1.9 Kg |
| Connectivity | Control via Bluetooth and RS485 port |
| Power supply | 115/230 V, 50/60 Hz |
| Length(m) | Width(m) | Height(m) | Weight(kg) | |
|---|---|---|---|---|
| Product | 0.15 | 0.48 | 0.04 | 2.20 |
