Professional Audio
MAX 4 FX USB BT
82MAR030
Bluetooth
REC
+48V
USB/SD
2 + 1 channel mixer. Player / Recorder.
MAX 4 FX USB BT is an audio mixer with 2 mono MIC / LINE channels and 1 stereo channel. Its MIC / LINE input channels incorporate phantom power for condenser microphones. MAX 4 FX USB BT features audio file player and recorder via USB / SD port, Bluetooth connectivity, built-in effects, 3 tone controls per channel, 5-band stereo graphic equalizer on the master, send / return connections , headphone output and balanced master outputs.
Features
- Audio player / recorder.
- Effects processor.
- Phantom power +48 V.
- Bluetooth, USB and SD.
| Input Channels | 2 Mic/Lin mono, 1 estéreo/ 2 Mic / Lin mono, 1 stereo |
| Gain range | + 10 a + 50 dB |
| Maximum output level | +28 dBu |
| Equalization | 12 KHz ± 15 dB, 3 KHz ± 15 dB, 80 Hz ± 15 dB |
| Phantom Power | +48 V |
| Power supply | AC 100-240 V 50/60 Hz / DC ± 15V / 48V (External power supply included) |
| Dimensions | 285 x 250 x 40 mm |
| Weight | 3 Kg |
| Other functions | USB / SD audio player / recorder, Bluetooth, Headphone out, Effects processor |
| Length(m) | Width(m) | Height(m) | Weight(kg) | |
|---|---|---|---|---|
| Product | 0.25 | 0.29 | 0.04 | 3.00 |
| Box | 0.47 | 0.05 | 0.38 | 3.00 |
| Master Carton | 0.49 | 0.35 | 0.40 | 18.00 |
- Audio mixer with: 2 mono MIC/LINE channels + 1 stereo channel.
- USB/SD player/recorder.
- +48V phantom.
- Effect included.
- 3 tone control on each input channel.
- 5 bands equalizer.
- AUX send/return connectivity.
- Headphone output.
Manual | MAX FX USB BT- series MANUAL v1.0 |  | Download |
