Lighting
LPX 12 DMX
56WLU012
DMX
12-channel DMX switch driver.
12-channel DMX and analogue switcher. The start address is configurable. With this device you can not only activate spotlights but also switch on/off effects, etc. Analogue signals take priority over DMX signals.
Features
- Control by DMX and analogue signals.
- Priority of analogue signals.
- Channel self-test function.
- Power failure memory.
| No. Channels | 12 |
| Connections | Power supply: internal terminals; Analogue signal: DIN 8; DMX signal: XLR 3; |
| Indicators | Backlit LCD display; Status indicator per channel |
| Power | 5 A por canal; 16 A Total/ 5 A per channel; 16 A Total |
| Protections | Fuse 5 A per channel |
| Power supply | Single phase AC 220-240V 50 Hz |
| Dimensions | 483 x 90 x 240 mm |
| Weight | 4,92 Kg |
| Length(m) | Width(m) | Height(m) | Weight(kg) | |
|---|---|---|---|---|
| Product | 0.24 | 0.48 | 0.09 | 4.92 |
| Box | 0.23 | 0.16 | 0.52 | 5.00 |
12 DMX/analog channel driver and chaser.
Analog signals have priority on DMX ones.
Channel autocheck functionOutput channels: 5A per channel ( 16 A max total load).
Memory against power supply failure.
Main supply: AC 220-240 V 50 Hz.
Dimensions (WxHxD): 483 x 90 x 240 mm.
Weight: 4.92 kg.
Analog signals have priority on DMX ones.
Channel autocheck functionOutput channels: 5A per channel ( 16 A max total load).
Memory against power supply failure.
Main supply: AC 220-240 V 50 Hz.
Dimensions (WxHxD): 483 x 90 x 240 mm.
Weight: 4.92 kg.
Manual | LPX 12 DMX - Manual | Download |
