- 70/100 volt line.
- EN 54-24 standard.
- 5VB plastic.
- Fireproof dome.
Personalised advice
Do you need help choosing your product? We will be happy to help you with your project.
| Type | Passive. EN 54-24 |
| L100V Power | 2000 Ohm( 5W) / 1000 Ohm (10W) / 500 Ohm (20W) |
| L70V Power | 1000 Ohm (5W) / 500 Ohm (10W) / 250 Ohm (20W) |
| Transducer | Woofer 6.5" |
| Frequency Range | 95 Hz - 20 KHz |
| Coverage | 500Hz: 180º, 1kHz: 180º, 2kHz: 150º. 4kHz: 5ñ, de acuerdo a EN 54-24 / 500Hz: 180º, 1kHz: 180º, 2kHz: 150º. 4kHz: 55º, according to EN 54-24 |
| Sensitivity | 92dB (1W@ 1m) (500Hz-5kHz) ruido rosa; 79dB (1W@ 4m) (100 Hz-10kHz) ruido rosa. De acuerdo a EN 54-24; 92dB (1W,1m) (100 Hz-10 kHz) ruido rosa. De acuerdo a EN 54-24/ 92dB (1W @ 1m) (500Hz-5kHz) pink noise; 79dB (1W @ 4m) (100Hz-10kHz) pink noise. According to EN 54-24; 92dB (1W, 1m) (100 Hz-10 kHz) pink noise. According to EN 54-24 |
| Max SPL | 105 dB |
| Mounting diameter | 157.1 mm |
| Mounting depth | 60 mm |
| Material | 5VB plastic |
| Colour | White |
| Dimensions | Ø199 x 72.1 mm |
| Weight | 0.88 Kg |
| Length(m) | Width(m) | Height(m) | Weight(kg) | |
|---|---|---|---|---|
| Product | 0.20 | 0.20 | 0.07 | 0.88 |
| Box | 0.25 | 0.24 | 0.10 | 1.34 |
| Master Carton | 0.49 | 0.51 | 0.33 | 13.28 |
IC 6520/54 | Acoustic Simulator
Optimise your IC 6520/54 with our Acoustic Simulator
With this online tool you can quickly design your PA system, calculating how many speakers and amplifiers you need and where to place them.
