Audio Installation

ARC SUB 12 MKIII

50ARC014
AMP

Amplified subwoofer. 200 W.

ARC SUB 12 MKIII is an amplified subwoofer integrating a 200 W power amplifier and a high-performance 12" woofer. The amplifier is equipped with various controls, allowing parameters such as output gain, bass boost, crossover frequency or phase inversion to be configured. The built-in standby function offers the possibility to switch off the amplifier in the absence of audio input. ARC SUB 12 MKIII features 2 input types: mono LINE full-range input and stereo High Level input for direct connection between external amplifiers and the satellite system.



Features

  • Made of high density wood.
  • Full-range and high-level inputs.
  • Automatic switch-on when audio signal is received.
TypeAmplified
Transducer12" woofer
Power200 W @ 4 Ohm / 200 W @ 4 Ohm
SensitivityLine: 500 mV, High Level: 8V
Frequency Response35 Hz - 200 Hz / 35 Hz - 200 Hz
Crossover50 Hz - 150 Hz (selectable)
ConnectionsRCA: Full-range or mono subwoofer LINE inputs and outputs; Banana: Stereo high-level inputs and outputs
Other functionsPhase inverter (From 0º to 180º), Bass Booster
Power supply115-230 V AC 50/60 Hz
Consumption240 W / 240 W
Dimensions380 x 400 x 434 mm / 380 x 400 x 434 mm
Weight24.2 Kg / 24.2 Kg
Length(m)Width(m)Height(m)Weight(kg)
Product0.430.390.4024.20
Box0.510.580.5424.20
  • 200W self-powered subwoofer.
  • Suitable for bass reinforcement appliances.
  • Standby function (Auto power on when receiving audio signal).
  • Full range and High Level inputs for different installation requirements.
  • Made of high density wood.
  • Several configuration parameters.
