Audio Installation

ARQ 16

50ARQ01650ARQ017
8Ohm
L100V

Passive loudspeaker

ARQ 16 is a passive loudspeaker designed for fixed installations, both in low impedance and on a 100 volt line, with a 160 W program at 8 Ohm or up to 40 W if used on a 100 volt line, with an impedance selector for this purpose.

Made of plywood, they incorporate a metal grid and their input connections are made through terminals.

Features

  • Suitable for low impedance and 70/100 volts line
Type2 ways. Passive
Low Impedance Power80 W RMS
L100V Power40 / 20 W
L70V Power20 / 10 W
Nominal Impedance8 Ohm
LF Transducer6.5" Woofer
HF TransducerCompression driver 1"
Sensitivity (1W @ 1m)86 dB
SPL Max.105 dB
Coverage Angle (H x V)90º x 60º
Frequency Range75 Hz - 20 KHz
ConnectionsTerminals
Enclosure materialPlywood
GrillIron
Inserts / RiggingWall bracket support (not included)
ColourBlack or white
Length(m)Width(m)Height(m)Weight(kg)
Product0.260.200.377.10
Box0.330.270.458.20
  Manual
Download
  Others
Download
