AMT 306

Ceiling Loudspeakers

Audio Installation

50AMT306

8Ohm

L100V

Ceiling loudspeaker.

AMT 306 is a ceiling loudspeaker for 100V line installation, it has 3 selectable power ratings (30/15/7.5W) and provides 30W @ Ohm. ABS plastic housing and metal grille. It incorporates a 6.5" Woofer + 1" Driver. Designed for commercial audio applications, obtaining a high performance in speech intelligibility and musical clarity. Its power selector, makes it adaptable to high impedance installations (with several positions), and low impedance. The loudspeaker body is made of ABS plastic and its metallic grille, fixed with magnets, covers the whole loudspeaker.

Translated with DeepL

Features

Open enclosure.
30W @ 8 Ohm.
30/15/7.5 W @ L100V.
Woofer 6.5 inches + Tweeter 1 inch.

Type	2-way. Passive
Low Impedance Power	30W @ 8 Ohm
L100V Power	30/15/7.5 W @ L100V
LF Transducer	6.5" woofer
HF Transducer	1" tweeter
Frequency Range	70 Hz - 20 KHz
Max SPL	88 dB

Mounting diameter	202 mm
Mounting depth	96 mm
Material	Housing: ABS plastic; Grille: metal
Colour	White
Dimensions	242 x 100 mm

	Length(m)	Width(m)	Height(m)	Weight(kg)
Product	0.24	0.24	0.10	0.10
Box	0.25	0.25	0.12	1.80
Master Carton	0.52	0.52	0.25	17.00

Elements: 6.5" woofer + 1" TWT.
Rated power.(100V line) : 40W/20W/10W.
Rated power. (8ohm): 40W.
Frequency response: 70 Hz - 20 Hz.
SPL ( @1W/1m) : 88dB.
Mounting Hole: Ø202x100 mm.
Dimensions: Ø242 mm.
Material: Metal (grille) ABS (enclosure).
